Electrostatically charged filter media is made of PP staple fiber and manufactured by needle punch process. Electrostatic was charged on the media with different ways so that the efficiency of the material could be in wide range of middle to high grade.
Our premium quality electrostatic filter media material is using in air conditioner, automotive cabin air, air purifier and other applications.
Wide efficiency range from F5 to H11. Unique electrical charge technologies to minimize charge degeneration effect;
Loose fibers structure of the "cotton mat" to ensure extremely low pressure drop;
Excellent higher dust holding capacity comparing to meltblown or other filter media;
Flexible combination with nonwoven protection and/or carrier layers to achieve excellent performance.
| Type | Area Weight (g/m²) | Thickness (mm) | Initial Efficiency* (%) | Pressure Drop* (Pa) | Structure | Max. Width (mm) | Max. Roll Length (m) |
| JK-D45% | 50 ±10 | 0.90 ± 0.1 | ≥45 | ≤2 | PP Cotton + PP protective layer | 1500 | 250 |
| JK-D65% | 50 ± 10 | 0.90 ± 0.1 | ≥65 | ≤3 | |||
| JK-D90% | 70 ±10 | 1.1 ± 0.1 | ≥90 | ≤4 | |||
| JK-D95% | 80 ±10 | 1.15 ± 0.1 | ≥95 | ≤4 | |||
| JK-PD45% | 110 ±10 | 1.05 ± 0.1 | ≥45 | ≤4 | PP protective layer + PP Cotton + PET backing layer | 1500 | 250 |
| JK-PD65% | 110 ±10 | 1.05 ± 0.1 | ≥65 | ≤5 | |||
| JK-PD90% | 130 ±10 | 1.3 ± 0.1 | ≥90 | ≤6 | |||
| JK-PD95% | 140 ±10 | 1.35 ± 0.1 | ≥95 | ≤6 | |||
| * Testing condition：0.3μm NaCl @ 5.3cm/s Carrier material can be customized according to requirement from customers. | |||||||
Enduring filtration efficiency with lower pressure drop and excellent dust holding capacity, our electrostatic “cotton mat” fit for various air filtration applications.
